Dimensions (cm): length 203x width 68 cm ± 5%.
The height of the bed surface is 53.5cm to 105cm±5%.
Mattress size: Head length: 45 cm Back length: 50 cm Foot length: 100cm
Electric arching angle in the middle of the mattress: 0° to +20°
Pneumatic control head plate section from angle +45° to -70°, foot plate section from angle 0° + 90°.
The body position of the treatment bed is changed into sitting and supine, different position adjustment and treatment
The electric motor is controlled by the bed surface lifting and surrounding type global foot switch.
The up and down adjustment function of the middle body position is a foot-controlled electric motor mechanism.
Attached with 3" bilateral central control brake double disc wheels, retractable casters, and the four corners can be raised and lowered.
Attached are 4 positioning adjustable foot pads, which can be adjusted according to the unevenness of the floor.
For prone treatment there are breathing holes.
There is a detachable paper roll holder at the end of the bed.
The safe working load and lifting capacity under normal use is 120kg.
  - All dimensions ±5%.
Material:
- The main body is made of iron and painted.
★The color is subject to the actual product
